Ubiquiti UniFi Network, Switch, 8-Port, POE 120W, (6) GbE PoE+ Ports, (2) GbE PoE++ Ports, (2) 10G SFP+ Ports, Layer 3, Wall Mount,

Ubiquiti Professional 8 PoE

Description: UniFi 8 port Managed Gigabit 8-port, Layer 3 switch with PoE+ and PoE++ output.

SKU: USW-Pro-8-PoE

Features:

• (6) GbE PoE+ ports
• (2) GbE PoE++ ports
• (2) 10G SFP+ ports
• 120W total PoE availability
• Application Requirements: UniFi Network Version 7.5.176 and later

Category: Network - UniFi / Switching

Overview

• Dimensions: 200 x 248 x 44 mm
  (7.9 x 9.8 x 1.7")
• Port Layout
• 1 GbE RJ45: 8 (6 PoE+; 2 PoE++)
  (1G/100M/10M)
• 10G SFP+: 2
  (10G/1G)
• Max. PoE Output: Up to PoE++
• Total PoE Availability: 120W
• Layer 3: Yes
• Form Factor: Compact desktop, wall

Performance

• Switching Capacity: 56 Gbps
• Total Non-Blocking Throughput: 28 Gbps
• Forwarding Rate: 42 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 16,000
• IPv4 Static Routes: 256
• Packet Buffer Size: 1.5 MB
• Access Lists
• IPv4: 128
• MAC: 128

Layer 3 Features

• DHCP Server (Local Networks): Yes
• DHCP Relay: Yes
• Inter-VLAN Routing (Local Networks): Yes
• Static Routing (Local Networks): Yes

Layer 2 Features

• LACP Port Aggregation: Yes
• STP & RSTP: Yes
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
• IGMP Snooping: Yes
• 802.1X Control: Yes
• MAC-Based ACLs & Device Isolation: Yes
• DHCP Snooping & Guarding: Yes
• Egress Rate Limit: Yes
• Flow Control: Yes
• Storm Control: Yes
• Multicast & Broadcast Rate Limiting: Yes
• MAC Address Blocking: Yes
• IP-Based ACLs & Network Isolation: Yes
• MAC-Based Port Restriction: Yes
• Port Isolation: Yes
• Port Mirroring: Yes
• Jumbo Frames: Yes
• LLDP-MED: Yes
• Voice VLAN: Yes
• Loop Protection: Yes
• Virtual Network Override: Yes

Hardware

• PoE Ports
• PoE+: 6
• PoE++: 2
• Max. PoE Wattage per Port by PSE
• PoE: 15.4W
• PoE+: 32W
• PoE++: 64W
• Max. Power Consumption: 30W (Excluding PoE Output)
  150W (Including PoE Output)
• Power Method: Universal input, 100–240V AC, 50/60 Hz
• Power Input Method: AC input
• Power Supply: AC/DC, internal, 150W
• Supported Voltage Range: 100–240V AC
• Management: Ethernet
  AR
• Heat Dissipation: 102.4 BTU/hr (Excluding PoE Output)
• Weight: 2.1 kg (4.6 lb)
• Enclosure Material: Polycarbonate, metal
• Mount Material: Polycarbonate
• Supported Rack Depth: 400~1200 mm
  (15.7-47.2")
• LCM Display: 1.3" touchscreen
• Ambient Operating Temperature: -5 to 45° C (23 to 113° F)
• Ambient Operating Humidity: 10 to 90% noncondensing
• NDAA Compliant: Yes
• Certifications: CE, FCC, IC, Anatel: 05214-24-08356

Software

• Application Requirements
• UniFi Network: Version 7.5.176 and later
