Ubiquiti Switch Enterprise 8-port PoE+ 8x2.5GbE, Ideal For Wi-Fi 6 AP, 2x 10g SFP+ Ports For Uplinks, Managed Layer 3 Switch,

Ubiquiti Enterprise 8 PoE

SKU: USW-Enterprise-8-PoE

The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3* switch with (8) 2.5GbE, 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

• (1) 1.3" LCM color touchscreen with AR switch management
• (8) 2.5GbE, 802.3at PoE+ RJ45 ports
• (2) 10G SFP+ ports
• 120W total PoE supply
• Wall-mountable (kit included)

* Layer 3 switching will become available in a future firmware update.
* Managed with the UniFi Network application: Version 6.3.51 and later

Category: Network - UniFi / Switching

Overview

• Dimensions: 200 x 248 x 44 mm
  (7.9 x 9.8 x 1.7")
• Port Layout
• 2.5 GbE RJ45: 8 (All PoE+)
  (2.5G/1G/100/10M)
• 10G SFP+: 2
  (10G/1G)
• Max. PoE Output: Up to PoE+
• Total PoE Availability: 120W
• Layer 3: Yes
• Form Factor: Compact desktop (Do not physically stack)

Performance

• Switching Capacity: 80 Gbps
• Total Non-Blocking Throughput: 40 Gbps
• Forwarding Rate: 60 Mpps
• Supported VLANs: 1,000
• MAC Address Table Size: 16,000
• IPv4 Static Routes: 256
• Packet Buffer Size: 1.5 MB
• Access Lists
• IPv4: 12
• MAC: 10

Layer 3 Features

• DHCP Server (Local Networks): Yes
• Inter-VLAN Routing (Local Networks): Yes
• Static Routing (Local Networks): Yes

Layer 2 Features

• LACP Port Aggregation: Yes
• STP & RSTP: Yes
• Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
• IGMP Snooping: Yes
• 802.1X Control: Yes
• MAC-Based ACLs & Device Isolation: Yes
• DHCP Snooping & Guarding: Yes
• Egress Rate Limit: Yes
• Flow Control: Yes
• Storm Control: Yes
• Multicast & Broadcast Rate Limiting: Yes
• MAC Address Blocking: Yes
• IP-Based ACLs & Network Isolation: Yes
• MAC-Based Port Restriction: Yes
• Port Isolation: Yes
• Port Mirroring: Yes
• Jumbo Frames: Yes
• LLDP-MED: Yes
• Voice VLAN: Yes
• Loop Protection: Yes
• Virtual Network Override: Yes

Hardware

• PoE Ports
• PoE+: 8
• Max. PoE Wattage per Port by PSE
• PoE+: 32W
• Max. Power Consumption: 30W (Excluding PoE Output)
  150W (Including PoE Output)
• Power Method: Universal input, 100–240V AC, 50/60 Hz
• Power Input Method: AC input
• Power Supply: AC/DC, internal, 150W
• Supported Voltage Range: 100–240V AC
• Management: Ethernet
  AR
• Heat Dissipation: 102.4 BTU/hr (Excluding PoE Output)
• Weight: 2.4 kg (5.3 lb)
• Enclosure Material: Polycarbonate
• Mount Material: Polycarbonate
• Supported Rack Depth: 400~1200 mm
  (15.7-47.2")
• LCM Display: 1.3" touchscreen
• ESD Protection: Air: ± 16kV, contact: ± 12kV
• Ambient Operating Temperature: -5 to 45° C (23 to 113° F)
• Ambient Operating Humidity: 10 to 90% noncondensing
• NDAA Compliant: Yes
• Certifications: CE, FCC, IC, Anatel: 06645-23-08356

Software

• Application Requirements
• UniFi Network: Version 6.3.51 and later
