Ubiquiti AC Mesh Dual-Band Antenna

SKU: UMA-D

Description: An optional mesh antenna designed to work with the AC Mesh.

Features:

• Compatibility: UAP-AC-M, UAP-AC-M-5
• Outdoor weather-resistant enclosure
• High-efficiency directional radiation pattern
• Dual-band, dual-polarity optimized for 802.11ac
• Ball joint 3-axis mount for precise aiming
• Wall and pole mount included

Category: Network - UniFi / WiFi 31

Mechanical

• Dimensions: 201.3 x 128 x 32.5 mm
  (7.9 x 5 x 1.3")
• Weight: Without mount: 400 g (0.9 lb)
  With mount: 480 g (1.1 lb)
• Enclosure Material: Outdoor UV-stabilized plastic

Hardware

• Supported Frequency Range: 2.4–2.5 GHz
  5.1–5.9 GHz
• RF Connections: (2) RP-SMA
• Gain
• 5 GHz: 15 dBi
• 2.4 GHz: 10 dBi
• HPOL Beamwidth
• 5 GHz: 45°
• 2.4 GHz: 90°
• VPOL Beamwidth
• 5 GHz: 45°
• 2.4 GHz: 90°
• Elevation Beamwidth
• 5 GHz: 45°
• 2.4 GHz: 90°
• Max VSWR: 2:1
• Polarization: Dual-linear
• Cross-Pol Isolation
• 5 GHz: 30 dB
• 2.4 GHz: 25 dB
• NDAA Compliant: Yes
• Certifications: Anatel: 06187-19-08356
