Ubiquiti PoE Adapter,Power UniFi PoE++ Devices,Reduce Dependency on PoE Switch Power, Provide a Multi-Gigabit LAN Connection

Ubiquiti 10G PoE++ Adapter (60W)

SKU: UACC-PoE++-10G

Description:
An adapter that can power UniFi PoE++ devices, reduce dependency on PoE switch power, and provide a Multi-Gigabit LAN connection.

Features:

• Delivers up to 60W of PoE++
• Surge, peak pulse, and overcurrent protection
• Contains RJ45 data input, AC cable with earth ground, and PoE++ output
• LED indicator for status monitoring

Category: Network - UniFi / POE & 31

Overview

• Dimensions: 106 x 63 x 34 mm
  (4.2 x 2.5 x 1.3")
• Weight: 210 g (7.4 oz)
• Power Cable: Included
• Output Voltage: 54V DC at 1.12A
• Rated Voltage: 100–240V AC at 50/60Hz
• Gigabit LAN Port: Yes
• 4-pair Powering: Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
• Clamping Protection: 11V Data, 60V power
• Data In / PoE: RJ45 Shielded Socket
• Input Current: 1.5A Max.
• Inrush Current: <150A peak at 230V AC
• Efficiency: >88%
• Switching Frequency: 65 kHz
• Output Ripple: 1% Max.
• Line Regulation: ≤ 2%
• Load Regulation: ≤ 5%
• Max. PoE+ Wattage per Port by PSE: 60W
• Max. Surge Discharge: 1500A (8/20 μs) power
• Peak Pulse Current: 36A (10/1000 μs) data
• Response Time: <1 ns
• Shunt Capacitance: <5 pF data
• Surge Protection: Difference and common mode
• Supported IEEE Standards: 802.3af (PoE 15.4 W)
  802.3at (PoE+ 30 W)
  802.3bt Type 3 (PoE++ 60 W)
• Ambient Storage Temperature: -30 to 70°C (-22 to 158° F)
• Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
• Ambient Operating Humidity: 10 to 95% noncondensing
• NDAA Compliant: Yes
• Certifications: CE, FCC, IC, UL, UKCA, KC, CCC, RoHS
