Ubiquiti UniFi Long-Range Ethernet Repeater, Receives PoE/PoE+, Offers Passthrough PoE Output, PoE Connections Up to 1 km

Ubiquit Long-Range Ethernet Repeater

SKU: UACC-LRE

Description:
The Long-Range Indoor/Outdoor Repeater (UACC LRE) is Gigabit adapter that allows you to easily and inexpensively expand your Ethernet network's range. With its (2) GbE RJ45 ports, the UACC LRE can receive PoE/PoE+ while providing passthrough PoE output. You can also chain multiple UACC LRE adapters together to connect access points and cameras that are far away from your PoE switch.

Features:

• Establishes long-range connections between PoE switches and devices, up to 1 km*
• Chains with other UACC LRE units

- (1) GbE RJ45 port for PoE/PoE+ input
- (1) GbE RJ45 port for passthrough PoE output

• 10kA+ surge protection
• Works reliably in extreme temperatures (-40 to 80° C)
• * Deployment tested: (9) daisy-chained UACC LRE units connected to an endpoint device (e.g., camera, AP) using (10) 100 m UISP Cable Pros, all powered a by UniFi PoE+ switch.
• *Repeaters must be placed in 100 m increments.
• *Powered with pins 1, 2+; 3, 6- which may not be supported by certain third-party switches. We recommend using a UniFi switch to power the device.

Category: Network - UniFi / POE & 31

Overview

• Dimensions: 196.5 x 93.5 x 39 mm
  (7.7 x 3.7 x 1.5")

Mechanical

• Weight: 350 g (12.3 oz)
• Enclosure Material: UV stabilized polycarbonate
• Mounting Material: Stainless steel
• Weatherproofing: IPX5

Hardware

• Power Method: PoE/PoE+ 2-pairs (Pins 1, 2+; 3, 6-)
• Max. Power Consumption: 1.5W (Excluding PoE output)
• Networking Interface: (2) GbE RJ45 ports
• PoE Interface: (1) Passthrough PoE output 2-pairs (pins 1,2+; 3,6-)
• Total Non-Blocking Line Rate: 2 Gbps
• Switching Capacity: 4 Gbps
• Forwarding Rate: 1.488 Mpps
• Total Available PoE: 22.5W
• Voltage Range PoE Mode: 37—57V DC
• ESD/EMP Protection: Air/contact: ± 30kV
• DC Sparkover Voltage: 90V at 100V/s
• Max. Impulse Sparkover Voltage: 700V at 1kV/μs
• Discharge Current: 10kA+
• Max. MTU: 1,500 bytes
• LEDs
• System: Blue: power ON
• Ethernet: Green: 1 Gbps
  Amber: 10/100 Mbps
• PoE: Amber: passthrough PoE out
• Ambient Operating Temperature: -40 to 80° C (-40 to 176° F)
• Ambient Operating Humidity: 10 to 95% noncondensing
