Ubiquiti 12U Rack Cabinet,Fully Assembled Wall-Mount Rack** No Fan Included** Removable Panels, Space-Efficient Small-Scale Deployment

Ubiquiti 12U Rack Cabinet ** No Fan Included**
SKU: UACC-Rack-12U-Wall-SW-P ** No Fan Included**

Description:
Fully assembled wall-mount rack with built-in fans and removable panels, engineered for easy equipment access and space-efficient small-scale deployments.

Compatibility:
UACC-Rack-Shelf-CLV, UACC-Rack-PM-Kit

Category: Network - UniFi / Data Rack Cabinets & 31

Overview

• Dimensions: Packaging: 725 x 840 x 735 mm (28.5 x 33.1 x 28.9")
  Rack: 600 x 700 x 639 mm (23.6 x 27.6 x 25.2")
• Weight: Packaging: 31.8 kg (70.1 lb)
  Rack: 25.8 kg (56.9 lb)
• Enclosure Material: SPCC steel
  Door/side panels: 1.2 mm (0.05")
  Main body: 1.2 mm (0.05")
  Posts: 2 mm (0.08")
• Color: White
• Treatment: Powder coating
• Rack Features
• U Height: 12U
• Rack Type: 4 post, enclosed cabinet
• Mounting Hole Type: Square
• Adjustable Mounting Depth: Default 434 mm (17.1")
  Max. 559 mm (22")
  Adjustable pitch 25 mm (1")
• Max. Weight Capacity: 80 kg (176 lb)
• Front Door: Perforated
  Default left-hand outswing, reversible
• Rear Door: Solid
  Swing-out
• Side Panels: (2) Solid, removable and lockable
• Mounting: Wall mount
• Fan Module: (2) Pre-installed 120 x 120 x 38 mm AC fan units (Input voltage: Region-specific; 110–120V AC for US models, 220–240V AC for EU models)
• Acoustic Noise: ≤ 50 dB(A) sound pressure level (Measured at 1 m in front of the enclosure, with cabinet empty (no installed equipment), under nominal fan operating conditions per ISO 7779)
• Grounding Lugs: Yes
• Cable Entry Opening: (1) Rear wall: 350 x 100 mm (13.8 x 3.9")
  (2) Top: 235 x 62 mm (9.3 x 2.4")
  (4) Top knockout: 35 mm (1.4")
  (1) Bottom: 235 x 62 mm (9.3 x 2.4")
  (4) Bottom knockout: 35 mm (1.4")
• Security: (1) Front door lock
  (1) Swing out door lock
  (4) Side panel locks
  (2) Keys
• Standard: CE; EIA/ECA-310-E; RoHS
• NDAA Compliant: Yes
